Femto-Photography: Visualizing Photons in Motion at a
Trillion Frames Per Second
Time-Lapse Visualization: Color coding of light with a delay of few picoseconds in each period
Frequently Asked Questions
How can one take a photo of photons in motion at a trillion frames per second?
We use a pico-second accurate detector. We use a special imager called a streak tube that behaves like an oscilloscope with corresponding trigger and deflection of beams. A light pulse enters the instrument through a narrow slit along one direction. It is then deflected in the perpendicular direction so that photons that arrive first hit the detector at a different position compared to photons that arrive later. The resulting image forms a "streak" of light. Streak tubes are often used in chemistry or biology to observe milimeter sized objects but rarely for free space imaging.
Can you capture any event at this frame rate? What are the limitations?
We can NOT capture arbitrary events at picosecond time resolution. If the event is not repeatable, the required signal-to-noise ratio (SNR) will make it nearly impossible to capture the event. We exploit the simple fact that the photons statistically will trace the same path in repeated pulsed illuminations. By carefully synchronizing the pulsed illumination with the capture of reflected light, we record the same pixel at the same exact relative time slot millions of times to accumulate sufficient signal. Our time resolution is 1.71 picosecond and hence any activity spanning smaller than 0.5mm in size will be difficult to record.
How does this compare with capturing videos of bullets in motion?
About 50 years ago, Doc Edgerton created stunning images of fast-moving objects such as bullets. We follow in his footsteps. Beyond the scientific exploration, our videos could inspire artistic and educational visualizations. The key technology back then was the use of a very short duration flash to 'freeze' the motion. Light travels about a million times faster than bullet. To observe photons (light particles) in motion requires a very different approach. The bullet is recorded in a single shot, i.e., there is no need to fire a sequence of bullets. But to observe photons, we need to send the pulse (bullet of light) millions of times into the scene.
What is new about the Femto-photography approach?
Modern imaging technology captures and analyzes real world scenes using 2D camera images. These images correspond to steady state light transport and ignore the delay in propagation of light through the scene. Each ray of light takes a distinct path through the scene which contains a plethora of information which is lost when all the light rays are summed up at the traditional camera pixel. Light travels very fast (~1 foot in 1 nanosecond) and sampling light at these time scales is well beyond the reach of conventional sensors (fast video cameras have microsecond exposures). On the other hand, LiDAR and Femtosecond imaging techniques such as optical coherence tomography which do employ ultra-fast sensing and laser illumination capture only the direct light (ballistic photons) coming from the scene, but ignore the indirectly reflected light. We combine the recent advances in ultra-fast hardware and illumination with a reconstruction technique that reveals unusual information.
What are the challenges?
Fastest electronic sensors have exposure time in nanoseconds or hundreds of picoseconds. To capture propagation of light in a tabletop scene we need sensor speeds of about 1 ps or one trillion frames per second. To achieve this speed we use a streak tube. The streak camera uses a trick to capture a one dimensional field of view at close to one trillion frames per second in a single streak image. To obtain a complete movie of the scene we stitch together many of these streak images. The resulting movie is not of one pulse, but is an average of many pulses. By carefully synchronizing the laser and camera we have to make sure each of those pulses look the same.
How will these complicated instruments transition out of the lab?
The ultrafast imaging devices today are quite bulky. The laser sources and high-speed cameras fit on a small optical bench and need to be carefully calibrated for triggering. However, there is parallel research in femtosecond solid-state lasers and they will greatly simplify the illumination source. In addition, progress in optical communication and optical computing shows great promise for compact and fast optical sensors. Nevertheless, in the short run, we are building applications where portability is not as critical.
| Light in Motion: Combination of modern imaging hardware and a reconstruction technique to visualize light propagation via repeated periodic sampling. |
